EQUIPMENT LIST



SHEARING:



1- CINCINNATI Autogage Pwr, 10’ X 10 Ga

1- WYSONG Autogage Pwr, 4’ X 12 Ga

1- DIACRO Precision Shear, 2’ X 16 Ga

1- PEXTO Foot Operated Shear, 3’ X 16 Ga


LASER:



1- MAZAK SPACE GEAR 48 2000W

1- MAZAK SUPER TURBO-X48 HI-PRO 1500W

1- MAZAK SUPER TURBO-X48 2500W

1- MAZAK X44 SUPER TURBO 4000W


CNC TURRET PRESSES:



1- AMADA EMK 3610NT, 33-60-100, 33 Ton, 58 Station W/ 4 Auto Index Stations, STEEL TRAK Slug Conveyer

1- AMADA VELA II, 30-50-50,  30 Ton, 44 Station w/Auto Index Station, Fanuc 6M Control, MP Auto Loader and Stacker, Turo Slug Conveyer & Self Dumping Hopper

1- AMADA PEGA, 30-40-40, 30 Ton, 56 Station, Fanuc 6M Control

1- AMADA PEGA KING, 30-40-50, 30 Ton, 44 Station w/Auto Index Station, Fanuc 6M Control


NOTCHING & ROLLING:



1- AMADA SW-220, 10 Ga Notch/Punch/Cope

1- PIRANHA Iron Worker

1- NIAGARA 36” X 10 Ga Metal Roller

1- DIACRO 24” X 14 Ga Metal Power Roller

1- DIACRO 12” X 20 Ga Metal Roller

1- DIACRO  8” X 20 Ga Metal Roller

1- DIACRO Bender #2


PUNCH PRESSES:



1- SEYI SL1-121 Ton

4- AMADA SPH 60, 60 Ton Hydraulic, Completely Automatic, 32.3” between uprights, 20.7” Throat

1- MIDWEST Hydraulic, 55 Ton

1- FAMCO Power Press, 15 Ton

53- FAMCO Kick Presses


DEBURRING:



1- TIMESAVERS Series 1200 - 24” Wide belt

1- TIMESAVERS Series 2200 - 36” Wide belt

1- TIMESAVERS 6” Mini-Belt Sander w/Vari-Speed Drive & Dust Collector

2- GRINDMASTER 37” Twin Head Belt Sanders, Abrasive Belt and Scotch-Brite Wheel w/Non Flammable Rand Bright SS Water Filled Dust Collector

1- INCOR ACIMALL LL3000 Belt Stroke Sander w/Power Table

1- OLYMPIC Belt Sander, 2” Belt

1- OLYMPIC Belt Sander, 4” X 62” Belt

2- BALDOR Grinder/Buffer

1- ULTRA-MATIC Vibratory Tumbler



FORMING:



3- DIACRO  4’ X 17 Ton

2- AMADA  RG-25     4’ X 25 Ton

2- AMADA  RG-50     6’ X 55 Ton

3- AMADA  RG-80     6’ X 88 Ton

3- AMADA  RG-80     8’ X 88 Ton

1- AMADA  RG-100   10’ X 110 Ton




WELDING:



1- UNITEK 132 16 KVA 3-Phase Welding System

5- LORS 20 KVA Single Phase Air Operated Spotwelder

1- LORS 40 KVA Single Phase Air Operated Spotwelder

1- SCIAKY 75 KVA Solid State 10” Gap, 36” Throat, 3-Phase Certified Class “A” Alum. Spotwelder

1- SCIAKY 200 KVA Solid State 10” Gap, 36” Throat, 3-Phase Certified Class “A” Alum. Spotwelder

1- MILLERMATIC 552-A Welder w/CP200

1- MILLERMATIC Flexcord w/CP300

1- MILLER 300 A/BP, AC/DC Tungsten Arc Welder, TIG

1- MILLER SYNCROWARE 350 AC/DC Tungsten Arc Welder, TIG

6- Silver Solder Torch Stations


HARDWARE INSTALLATION:



2- HAGER High Speed Model 824-2 Window Touch 2 – Fastener Insertion System

1- HAEGER Model HP6-B

1- HAEGER Model HP6-B w/Auto Feed

2- HAEGER Model AF-A w/Auto Feed

1- AUTO-SERT Hardware Machine, AS-7 Auto Feed


HEAT TREAT:



1- IPSEN Model VCW214 Vacuum Heat Treat System w/Honeywell Graph Recorder 14”X16”X26”

1- LUCIFER Heat Treat Oven, 24” X 24” X 28”, Barker-Coleman Temperature Controls

1- PARAGON Heat Treat Furnace, Model OTC100, 250-2400 degrees


MACHINING:



1- MAZAK PFH-4800 Horizontal Machining Center

1- YANG SMV-1000 Vertical Machining Center w/Fanuc Control, 40” X 20” Table

1- CHEVALIER Knee Mill J2 Head, 18” X 34”

1- BRIDGEPORT J2 Head Vertical Mill, 13” X 26”

1- BRIDGEPORT J Head Vertical Mill, 13” X 26”

1- VAN NORMAN Horizontal Mill

7- Drill Press, 15” or larger

2- NICHOLS Twin Mills

1- EISELE Autofeed Saw


TOOLING:



1- MITSUBISHI DWC 11-H Wirecut EDM System – Cutting Area 11” X 17” X 8”

3- BRIDGEPORT Vertical Mill J2 Head, Power Feed and DRO’S, 13” X 26”

1- KENT Surface Grinder, 12” X 24”

1- CHEVALIER Grinder, 8” Wheel, 6” X 18”

1- ROLL-IN Band Saw, 10” max cut

1- HARDINGE Tooling Lathe, 10” max cut


MILLS & DRILL PRESSES:



          2- #2 BURGMASTER Turret Drill and Tapping Presses

1- ONSRUD R0-117 Router

2- PROCUNIER Tapping Machine


LATHES:



1- MAZAK NEXUS 100 Quick Turn CNC Lathe w/Bar Loader

1- CLAUSING COLCHESTER 15”

2- HARDINGE Secondary Operation Machine

1- HARDINGE Engine Lathe


SAWS:



1- Table Saw

1- ROLL-IN Cutoff Saw

1- CONTOURMATIC Band Saw

1- HaBERLE H350 Cold Saw

1- KMT Cold Saw Model SIRIO 350 AF-E W/Autofeed


GRINDING:



1- BOYAR SCHULTZ Surface Grinder, 6” X 16”

1- Centerless Grinder, 1/16” X 1 ½”

1- BALDOR Polishing Lathe

1- THOR Bench Grinder

2- Pedestal Grinders


PACKAGING:



1- VERSA PACKER 19” Foaming System


ENGRAVING:



1- HERMES 7200 w/Plotter, 11” X 17” Table – Hermes Software


INSPECTION:



1- MITUTOYO Coordinate Measuring Machine –40” X 40” X 28” Table- w/Virtual DMIS Software and a Renishaw PH1 Touch Probe

2- MICRO VU H14 Floor Model Optical Comparator

1- WILSON Hardness Tester, Superficial

1- WILSON Model 220 Micro Hardness Tester

1- “CAL-TESTER” Tensil Tester, 0-10,000 lbs. (certified)

1- BROWN & SHARPE  36” Micro-Hite

1- AMADA Fabrivision L, FVL-HD-4848
